Technical Specifications
Product Overview
Metallurgical Characteristics
718 Pre-hard steel features a tempered martensitic microstructure with fine carbide distribution, achieved through MetalZenith's controlled quenching and tempering processes. The optimized chemical composition provides excellent through-hardening capability while maintaining superior machinability in the pre-hardened condition.
Heat Treatment Process
Our proprietary heat treatment involves austenitizing at 850-870°C, followed by controlled quenching in polymer or oil medium, and tempering at 580-620°C to achieve the desired hardness range of 30-36 HRC. This process ensures uniform hardness distribution and optimal stress relief throughout the material cross-section.
Manufacturing Process
MetalZenith employs electric arc furnace melting followed by ladle refining and vacuum degassing to achieve superior cleanliness. The steel undergoes forging or rolling to break down the cast structure, followed by spheroidizing annealing for optimal machinability before final heat treatment to the pre-hardened condition.
Quality Standards & Testing
Every production lot undergoes comprehensive testing including chemical analysis by optical emission spectroscopy, mechanical property verification, ultrasonic inspection for internal soundness, and dimensional verification. Our quality management system complies with ISO 9001:2015, AS9100D, and NADCAP standards, ensuring consistent material properties and full traceability from raw materials to finished products.
🧪 Chemical Composition
| Element | Composition (%) |
|---|---|
| Carbon (C) | 0.28 - 0.40 |
| Silicon (Si) | 0.20 - 0.80 |
| Manganese (Mn) | 0.60 - 1.00 |
| Phosphorus (P) | ≤ 0.030 |
| Sulfur (S) | ≤ 0.030 |
| Chromium (Cr) | 1.40 - 2.00 |
| Nickel (Ni) | 0.30 - 1.20 |
| Molybdenum (Mo) | 0.15 - 0.40 |
| Aluminum (Al) | 0.020 - 0.050 |
| Copper (Cu) | ≤ 0.25 |
⚙️ Mechanical Properties
| Property | Value |
|---|---|
| Hardness (Pre-hardened) | 30 - 36 HRC |
| Tensile Strength | 1000 - 1200 MPa |
| Yield Strength (0.2% offset) | ≥ 850 MPa |
| Elongation | ≥ 12% |
| Reduction of Area | ≥ 40% |
| Impact Energy (Charpy V-notch) | ≥ 25 J |
| Young's Modulus | 210 GPa |
| Fatigue Limit (10&sup7; cycles) | 450 MPa |
| Poisson's Ratio | 0.27 - 0.30 |
🔬 Physical Properties
| Property | Value |
|---|---|
| Density | 7.85 g/cm³ |
| Melting Point | 1450 - 1520°C |
| Thermal Conductivity (20°C) | 42 W/m·K |
| Thermal Expansion Coefficient (20-100°C) | 11.5×10-6/K |
| Thermal Expansion Coefficient (20-200°C) | 12.1×10-6/K |
| Specific Heat Capacity | 460 J/kg·K |
| Electrical Resistivity | 0.25 µΩ·m |
| Magnetic Permeability | Ferromagnetic |
| Thermal Diffusivity | 11.6 mm²/s |
📏 Product Specifications
| Specification | Available Options |
|---|---|
| Product Forms | Flat bars, Round bars, Square bars, Plates, Blocks |
| Thickness Range | 10 - 300 mm |
| Width Range | 50 - 2000 mm |
| Length Range | Up to 6000 mm |
| Round Bar Diameter | 20 - 500 mm |
| Surface Finish | Hot rolled, Annealed, Ground, Polished |
| Dimensional Tolerance | ±0.5 mm (Standard), ±0.1 mm (Precision) |
| Standards Compliance | ASTM A681, DIN 1.2311, JIS SKT4, GB 3Cr2Mo |
| Surface Roughness | Ra 0.8 - 3.2 µm |
| Flatness Tolerance | ≤ 0.5 mm/m |
Let Us Create Success for Your Project
Professional Team, Premium Products, Complete Service - Your Project Success is Our Mission
Our Advantages in Processing 718 Pre-hard
Advanced Vacuum Melting Technology
MetalZenith employs state-of-the-art vacuum induction melting (VIM) and electroslag remelting (ESR) processes to achieve exceptional cleanliness and homogeneity. Our controlled atmosphere production eliminates inclusions and ensures uniform chemical composition throughout the steel matrix.
Precision Heat Treatment Control
Our proprietary computer-controlled heat treatment processes deliver consistent hardness distribution of 30-36 HRC throughout the entire cross-section. Advanced quenching and tempering techniques ensure optimal stress relief and dimensional stability for precision machining.
Comprehensive Customization Services
MetalZenith offers extensive customization including precision cutting, surface grinding, and specialized heat treatment modifications. Our global supply chain and flexible production capabilities ensure rapid delivery of custom sizes and specifications to meet specific application requirements.
