Technical Specifications
Product Overview
Metallurgical Characteristics
IS 2062 exhibits a predominantly ferritic-pearlitic microstructure with fine grain size achieved through controlled rolling practices. The optimized carbon content and manganese levels provide excellent balance between strength and ductility, while controlled phosphorus and sulfur content ensures superior weldability and formability essential for structural applications.
Heat Treatment Process
MetalZenith employs controlled hot rolling at temperatures between 1050-1200°C followed by controlled cooling to achieve optimal mechanical properties. Normalization at 900-950°C may be applied for enhanced uniformity and stress relief, particularly for thick sections used in critical structural applications.
Manufacturing Excellence
Our advanced production process incorporates continuous casting, controlled rolling with precise temperature monitoring, and accelerated cooling techniques. This ensures consistent mechanical properties, excellent surface quality, and dimensional accuracy critical for structural fabrication and construction applications.
Specialized Quality Testing
MetalZenith conducts comprehensive testing including welding performance evaluation using standard procedures, formability assessment through bend and cup tests, fatigue strength testing for cyclic loading applications, and atmospheric corrosion resistance evaluation for outdoor structural applications. Impact testing at various temperatures ensures reliable performance in diverse climatic conditions.
Application Engineering
For building frameworks, our IS 2062 provides optimal strength-to-weight ratio and excellent connection reliability. In bridge construction, the superior fatigue resistance and atmospheric corrosion performance ensure long-term structural integrity. For machinery manufacturing, the excellent machinability and weldability enable complex fabrication. In automotive applications, the consistent mechanical properties and formability support efficient manufacturing processes.
🧪 Chemical Composition
| Element | Composition (%) |
|---|---|
| Carbon (C) | ≤ 0.23 |
| Manganese (Mn) | 0.50 - 1.50 |
| Silicon (Si) | ≤ 0.40 |
| Phosphorus (P) | ≤ 0.050 |
| Sulfur (S) | ≤ 0.050 |
| Aluminum (Al) | ≥ 0.020 |
| Chromium (Cr) | ≤ 0.30 |
| Nickel (Ni) | ≤ 0.30 |
⚙️ Mechanical Properties
| Property | Value |
|---|---|
| Yield Strength (MPa) | ≥ 250 |
| Tensile Strength (MPa) | 410 - 540 |
| Elongation (%) | ≥ 23 |
| Impact Energy at 0°C (J) | ≥ 27 |
| Hardness (HB) | 120 - 160 |
| Bend Test | 180° without cracking |
🔬 Physical Properties
| Property | Value |
|---|---|
| Density (g/cm3) | 7.85 |
| Melting Point (°C) | 1510 - 1540 |
| Thermal Conductivity (W/m·K) | 50.2 |
| Thermal Expansion (×10??/K) | 11.8 |
| Elastic Modulus (GPa) | 200 |
| Poisson's Ratio | 0.27 - 0.30 |
📏 Product Specifications
| Specification | Details |
|---|---|
| Available Forms | Plates, Sheets, Beams, Channels, Angles, Bars |
| Thickness Range | 3 - 80mm |
| Width Range | 1000 - 3000mm |
| Length Range | 6000 - 12000mm |
| Standards Compliance | IS 2062, ASTM A36 equivalent |
| Heat Treatment Condition | Hot Rolled, Normalized |
| Surface Finish | Mill Scale, Pickled, Shot Blasted |
Let Us Create Success for Your Project
Professional Team, Premium Products, Complete Service - Your Project Success is Our Mission
Our Advantages in Processing IS 2062 Steel
Advanced Controlled Rolling Technology
MetalZenith employs precision controlled rolling with optimized temperature profiles and reduction schedules to achieve superior grain structure and enhanced mechanical properties. Our advanced processing ensures consistent strength and excellent formability throughout the material cross-section, critical for structural applications.
Comprehensive Structural Testing
Our rigorous quality assurance includes specialized testing for structural applications: welding performance evaluation, bend testing for formability, fatigue strength assessment, and atmospheric corrosion resistance testing. This ensures optimal performance in demanding structural environments.
Custom Structural Solutions
MetalZenith provides tailored processing services including precision cutting, forming, and heat treatment optimization. Our technical team offers comprehensive support for structural design requirements, ensuring optimal material selection and processing for specific construction and engineering applications.
